Zoom B2 Four Bass Multi-Effects Processor

( 0 Reviews )
Rs. 27,019.00 Rs. 20,559.00

Inclusive of all GST

Specs

MAXIMUM NUMBER OF SIMULTANEOUS EFFECTS 5
USER PATCH MEMORIES 300
A/D CONVERSION 24-bit 128× oversampling
D/A CONVERSION 24-bit 128× oversampling
SIGNAL PROCESSING 32-bit
DISPLAY 256×128 dot-matrix LCD

Inputs

INPUT Standard mono phone jack Rated input level: −20 dBu
  Input impedance (line): 1 or 10 MΩ (switchable)
AUX INPUT Stereo mini jack Rated input level: −10 dBu
  Input impedance (line): 10 kΩ


Outputs

LEFT/RIGHT Standard mono phone jacks Maximum output level: +11.4 dBu (when output impedance 10 kΩ or higher)
BALANCED OUTPUT XLR jack Impedance: 100 Ω (HOT-GND, COLD-GND)/200 Ω (HOT-COLD) GND LIFT (switchable)
PHONES Stereo mini jack Maximum output power: 33 mW + 33 mW (into 32Ω load)
INPUT S/N 124 dB



Noise floor (residual noise)

LEFT/RIGHT –96.0 dBu
BALANCED OUTPUT –100.0 dBu
PHONES –96.0 dBu
CONTROL INPUT FP02M input
POWER AC adapter: 9V DC 500mA center negative (ZOOM AD-16)
USB USB 2.0 Type-C port (use cable that supports Type-C) HandyGuitar Lab: USB 1.1 Full Speed Audio interface: USB 2.0 Full Speed, 32-bit, 2-in/2-out • Use a USB cable that supports data transfer. USB bus power is supported.
DIMENSIONS 146 mm (D) × 249 mm (W) × 72 mm (H)
WEIGHT 906 g
NOTE: 0 DBU = 0.775 V

Details

Features:

  • 6 built-in DI models: 3 tube and 3 solid state
  • 11 realistic amp/cabinet models with newly developed Multi-Layer IR
  • 11 preamp models (including 3 ZOOM original models)
  • 82 bass effects including modeling of famous boutique pedals
  • Analog input circuit with excellent low-frequency response
  • Use up to 5 effects simultaneously
  • 300 Patch Memories (250 Preset Patches with historic bass tones)
  • 60 Second Looper + 68 rhythm patterns
  • USB port for Handy Guitar Lab connection, 2-in/2-out audio interface and firmware updates
